FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH
  • name
  • name
  • name
  • name

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH

MOQ: 300 kg
Price: 18~29USD/KG
Standard Packaging: each roll weight 53~58kg into box, then 16roll packing into pallet
Delivery Period: after get payment into 10days delivery to Chinese port
Payment Method: L/C, T/T, D/A, Western Union, MoneyGram
Supply Capacity: 8000KGS/PER MONTHS
Detail Information
Product Description
Detail Information
Place of Origin
XUCHANG
Brand Name
NEWDESEN
Certification
ROHS, UL
Model Number
hgh
Brand:
NEWDESEN
Width:
900mm Or 920mm
Colour:
GOLD YELLOW
Temperature Class:
Class H
Material:
NON-ALKALI FIBERGLASS CLOTH With POLYIMIDE FILM
Thickness:
0.15~0.40mm
Place Of Origin:
XUCHANG
Roll Weight:
53~58kg Per Roll
HS CODE:
392069
Product Description

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM hgh FIBERGLASS CLOTH

the HGH flexible composite Made of two layers of polyimide film on both sides, and with one layer of alkali-free fiberglass

cloth in the middle.



can provide thickness:

0.13mm, 0.15mm, 0.18mm, 0.20mm ,0.25mm ,0.30mm ,0.33mm, 0.35mm, 0.38mm, 0.40mm, 0.45mm 0.50mm .width:914mm





Features:

1.It is bonded by H class adhesive, two layers of Polyimide film on both sides and one layer of alkali-free fiberglass cloth in the middle.
2.It is with excellet dielectric properties, mechanical strength, tearing strength and long time thermostability at low or high temperature.
3.Be used as slot insulation, liner insulation, interlayer insulation of motor, transformer or other electrical appliances.
4.Insulation Class: H Class (180℃)
5.Appearance: Smooth, beautiful, shining.



Application Remarks

MGM composite flexible  is mainly used as a slot liner,slot closure, phase-to-phase and turn-to-turn insulation in low or medium voltage electrical motors of Class F (155℃) or Class H (180℃) insulation system ,in addition, its also used as interlayer insulation in transformers and other electrical machines and appliances



Package :

hgh fiberglass laminated sheet ,usually we will be packed by three-layer, the first layer is a plastic film, the second layer is a carton plus a packing tape, and the third layer is wrapped with a plastic film. This will prevent the goods from getting wet and rubbed during transportation and ensure that the product arrives at your destination in good condition.



FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 0



Performance requirements as follows

Name
Unit
Value
Thickness
mm
0.20
Melting point
℃
non-fusible
Dimensional stability at high temperature
150℃
≤0.35
400℃
≤2.50
Tensile strength
MD
no bending
N/10mm
≥330
After bending
≥290
CD
no bending
≥310
After bending
≥270
Volume resistivity
Ω·m
≥1.0×1010
Breakdown Voltage
no bending
KV
15
After bending
13
Elongation at break
MD,no bending
%
≥50
CD,no bending
≥50
alternating current electric strength
no bending
KV
≥25
After bending
≥23
Long time thermostability,Insulation Class
/
℃
180



FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 1

Mobile: 86 139 0374 4063

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 2

Mail: creditzf@163.com

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 3

Skype: zhufenglisa

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 4

 Wechat : 70707314

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 5

  QQ: 707073142

FLEXIBLE COMPOSITE INSULATING MATERIAL POLYIMIDE FILM HGH FIBERGLASS CLOTH 6

WHATSAPP:86 139 0374 4063
