| Place of Origin: | HENAN |
| Brand Name: | NEWDESEN |
| Certification: | ISO1998,ROHS |
| Model Number: | POLYESTER SHRINKABLE TAPE |
| Minimum Order Quantity: | 50000maters |
|---|---|
| Price: | 0.01~0.20USD |
| Packaging Details: | The inside package is plastic bag, and the outside packed by carton or pallet for Heat shrinking fiber tape. |
| Delivery Time: | After get payment into 20days delivery to China |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram, D/P, D/A |
| Supply Ability: | 15~30days finished 5tons |
| Tape: | Insulation | Standard: | Standard |
|---|---|---|---|
| Sample: | Sample Supplied | Usage: | Insulation Protection |
| Feature: | Electrical Performence | Color: | White |
| Width: | 20~40mm | Thickness: | 0.20~0.25mm |
| Shrinking Rate: | 10% And 40% |
Applications of Heat Shrink Polyester Tape:
-As insulating binding materials for electric motors,coil of transformers.
Availability of Heat Shrink Polyester Tape:
-Rolls: 10mm,15mm,20mm,25mm,30mm,50mm width.
Other spec. can be produced on request.
-Colour line in the middle is available on request.
Name: heat shrinkable tape & polyester shrinkable tape &Polyester shrinkable insulation binding tape
Usage: Insulation Protection material
Type: Insulation Tape
Material: polyester shrinkable fiber Feature: Heat-Resistant
Application: heat Polyester shrinking insulation tape Rated Voltage: 40KV
Tensile Strength: 200N/10mm Item: electrical binding tape
Thickness: 0.15mm -0.30mm or customized
Width: 10~60mm or customized Length: 25~100m or customized
Texture: Plain
shrinkage rate: 10% ~ 13% and 35% ~ 43%
Color: White
Polyester shrinking tape technical date:
| NO. | Items | Units | Values |
| 1 | Broken warp | / | Every tray is made up of two segments, the length of each is not less than 3 meters |
| 2 | Broken-ends | / | No more than 200mm single broken end, no more than 30mm two broken ends |
| 3 | Besmirch | / | No oil stain, no rust |
| 4 | Pinholing | / | No broken warp and end at the same time, no more than 3 pinholing |
| 5 | Shrinkage | % | ≥30 |
| 6 | Tensile strength | N/10mm | ≥200 |
