| Place of Origin: | HENAN |
| Brand Name: | NEWDESEN |
| Certification: | ISO1998;ROHS,UL |
| Model Number: | INSULATION TAPE |
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Price: | 0.3-3.6USD/PCS |
| Packaging Details: | carton and pallet |
| Delivery Time: | after get payment into 20days delivery to China |
| Payment Terms: | L/C.D/A.D/P.T/T.WESTEN UNION |
| Supply Ability: | 15-30days finished 5tons |
| Color: | White | Brand Name: | NewDesen |
|---|---|---|---|
| Application: | High Temperature | Width: | 10mm-100mm |
| Thickness: | 0.08-0.30mm | Model Number: | Electrical Insualtion Fiberglass |
| Form: | In Roll | PACKAGE: | CARTON And PALLET |
Alkali fiber glass tape is pliable and tacky. Its web structure provides easy unwind without glass strands separation an overlapping.The product contributes the characteristics of high tensile strength, high resistance to shocks, high modulus of elasticity, dimensional stability as well as no magnetically confining and eddy currents losses.High temperature resistance Good insulation
2.Specifications:
Thickness:0.08mm;0.1mm;0.13mm;0.15mm;0.2mm;0.25mm;0.30mm etc.
Width:10mm;15mm;20mm;25mm;30mm;50mmmm;........100mm;
Length:30m,50m,100m,200m
Package:5 rolls or 10 rolls per heat shrinkable film.
|
Thickness mm |
Width mm |
Tolerance mm |
Density (ends/cm) | Tensile Strength(N/strip 10X100mm not less than) | Texture | |
| warp | abb | |||||
| 0.100±0.010 | 13,15 | ±1 | 27±2 | 15±1 | 200 | Plain Weave |
| 20,25 | ±2 | |||||
| 0.170±0.015 | 20,25 | ±2 | 27±2 | 15±1 | 270 | Plain Weave |
Storage Conditions :
Stored in a clean,dry,ventilated place,keep away from fire and heating,avoid direct sunlight.
3. Applications:
non-alkali fiberglass tape can be widely used as ideal banding materials for electrical motors, transformers and lightning arresters
4. Thickness: 0.08mm; 0.1mm; 0.13mm; 0.15mm; 0.2mm; 0.25mm etc.
Width: 10mm, 15mm, 20mm, 25mm, 30mm, 50mmmm,........100mm,
Length: 30m, 50m, 100m,
5. Package: 5 rolls or 10 rolls per heat shrinkable film, then put it into carton.
6. Why you choose us?
1) High performance cost ratio with steady quality
2) OEM service and Prompt Delivery
3) The fast speed of reply your email and can make quotation sheet just for you.
4) Can provide free sample, only need you bear the sample fee.
5) Supply good after-sales service, we will follow-up the situation after using, if have problems, we will find out the reason and deal with positively.
7. Packing:
exporting cartons and pallet
8. Delivery time and payment terms:
1) 10-20 days usually, if quantity is large, the lead time is around 30 days
